TR-HT01 Fully Automatic High-speed Double-head Insert Plastic Shell Tin Dipping Machine

Equipment function: the front and rear ends are pierced through the shell, and the front end can be pierced through the shell and the rear end can be dipped in tin

Cost saving: the front and rear ends are pressed through the shell, and the rear end is dipped in tin. All processes are automatically completed, saving production costs for customers.

Good stability: The crimping end adopts eccentric shaft and cam structure, the crimping force of the terminal is balanced, the crimping of the terminal is neat, and the consistency is good.

High precision: Servo motors are used to control cutting, peeling, pressure end positioning, shell feeding, shell piercing, and precise positioning.

Simple operation: touch screen operation, easy parameter setting and operation, easy to understand at a glance, ordinary employees only need simple training, and one person can operate several devices.

Device name:Fully automatic double-head pressing end shell inserting machine

Length x Width x Height:2183x2350x1800mm

Equipment Weight:About 1100KG

Working Pressure:0.5-0.7Mpa, the air source is filtered and dry

Operating Voltage:AC220V 50HZ

Rated Current:45A

Control:Inovance bus

Servo/Stepper Motor:Inovance Servo Motor/Raise Stepper Motor

Screw/rail: TPI screw/silver guide rail

Sensor: Hua Yifeng

Cyndiner:Genuine brands such as SMC AirTAC

Detection (optional):Vision (Tongyue), Pressure (Tyco)

Efficiency:300~375 times/hour (efficiency fluctuates with the number and length of spelling,

                while wearing multiple plastic shells and working continuously for 24 hours)

Cut length:45-1000mm (length can be customized)

Front end:Stripping 0-5mm, punching terminals, piercing the shell

Rear end:Stripping 0-10mm, twisting 2-8mm, tinning, terminal punching, casing penetration

Type of wire: AWG28#-18# electronic wire, cable

Shell type:1.25\1.5\2.0\2.5\3.96 etc.

Shell processing P number:2P-5P (cable) 2P-20P (electronic wire)
