TR-DM02 Double-head Double-piercing Inserting Number Tube Punching Terminal Crimping Machine

TR-DM02 Double-head Double-piercing Inserting Number Tube Punching Terminal Crimping Machine

TR-DM02  Double-head Double-piercing Inserting Number Tube Punching Terminal Crimping Machine
TR-DM02  Double-head Double-piercing Inserting Number Tube Punching Terminal Crimping MachineTR-DM02  Double-head Double-piercing Inserting Number Tube Punching Terminal Crimping MachineTR-DM02  Double-head Double-piercing Inserting Number Tube Punching Terminal Crimping MachineTR-DM02  Double-head Double-piercing Inserting Number Tube Punching Terminal Crimping MachineTR-DM02  Double-head Double-piercing Inserting Number Tube Punching Terminal Crimping Machine
CategoriesInserting Tube Terminal Crimping Machine
BrandTuring
ModelTR-DM02
PowerAC220V/50HZ,
ApplicationDouble-head Terminal Machine
FeatureStable Performance
Warranty1year
ControlServo and Step motor
ContactLily 0086-13715588365
FunctionWire Stripping Cutting Wear Number Tube terminal
FOB portshenzhen ,guangzhou ,zhongshan
Terms of PaymentWestern Union, MoneyGram, T/T
Download
Update TimeJun 24,2024
Detail Information
TR-DM02  Double-head Double-piercing Inserting Number Tube Punching Terminal Crimping Machine
Program brief:
Cutting and stripping the wires, crimping at both ends, printing the number tube, threading the number tube, and baking the number tube
Function introduction:
Wire cutting, single-end stripping, both-end stripping, both-end crimping, double-end crimping and baking number tube

                                                 EQUIPMENT NAME
 AUTOMATIC DOUBLE-THREADED NUMBER TUBE DOUBLE HEAD TERMINATION MACHINE
STRIP LENGTH
Front0.5~80mm Rear 0.1~10.0mm
EQUIPMENT SIZE
 W800*D1800*H1800mm
WORK EFFICIENCY
Wire length 80-150mm approx.900 pcs/hour, special wire approx. 700 pcs/hour
EQUIPMENT WEIGHT
About 800KG
PROCESSING OF WIRES
#22~#14AWG
OPERATING VOLTAGE
Single Phase AC200V~242V50/60Hz 10A
CUTTING ACCURACY
Line length below 100mm Error 0.2+(line length x 0.002), Line length above 100mmTolerance 0.5+(line length x 0002)
PROCESSING LENGTH
Leave rubber in the center 66mm~99999mm
DEPTH OF CUT
Maximum adjustment 5.50mm, resolution 0.01mm
SENSOR
Low air pressure, presence or absence of wires, abnormal pressure, abnormal entry wires
COMPRESSED AIR
0.5 MPa(5 kgf / cm2) clean dry gas
PRODUCT FEATURES
1.Cutting and stripping, 2.Pressing the end, 3.Cutting off the wire                4.Threading and baking,5.Printing the number tube

TR-DM02  Double-head Double-piercing Inserting Number Tube Punching Terminal Crimping Machine
TR-DM02  Double-head Double-piercing Inserting Number Tube Punching Terminal Crimping Machine
TR-DM02  Double-head Double-piercing Inserting Number Tube Punching Terminal Crimping Machine
TR-DM02  Double-head Double-piercing Inserting Number Tube Punching Terminal Crimping Machine
TR-DM04 automatic double-head wear number tube tube type terminal machine
TR-DM04 automatic double-head wear number tube tube type terminal machine
TR-DM04 automatic double-head wear number tube tube type terminal machine
TR-DM04 automatic double-head wear number tube tube type terminal machine
TR-DM04 automatic double-head wear number tube tube type terminal machine
TR-DM04 automatic double-head wear number tube tube type terminal machine
TR-DM04 automatic double-head wear number tube tube type terminal machine
TR-DM04 automatic double-head wear number tube tube type terminal machine
Wire cutting, single-end stripping, both-end stripping, both-end crimping, double-end crimping and baking number tube
