TR-H14 Semi-automatic Heat Shrink Tube Baking Machine

TR-H14 Semi-automatic Heat Shrink Tube Baking Machine

TR-H14 Semi-automatic Heat Shrink Tube Baking Machine
TR-H14 Semi-automatic Heat Shrink Tube Baking MachineTR-H14 Semi-automatic Heat Shrink Tube Baking MachineTR-H14 Semi-automatic Heat Shrink Tube Baking MachineTR-H14 Semi-automatic Heat Shrink Tube Baking MachineTR-H14 Semi-automatic Heat Shrink Tube Baking Machine
CategoriesInserting Tube Machine and Heat Shrink Tube Baking Machine
BrandTuring
ModelTR-H14
PowerAC220V/50HZ,
ApplicationSemi-automatic Heat Shrink Tube Baking Machine
FeatureStable Performance
Warranty1year
ContactCoco 0086-18666170785
FOB portshenzhen ,guangzhou ,zhongshan
Terms of PaymentWestern Union, MoneyGram, T/T
Download
Update TimeDec 3,2024
Detail Information
TR-H14 Semi-automatic Heat Shrink Tube Baking Machine
Applicable wires:Electronic wire, silicone wire, multi-core wire, multi-core over-powdered wire, isolation wire, etc.
Size & weight:L500 x W640 x H1300mm,Approx. 78KG
power supply:1350W AC220V50/60HZ
capacities:1500pcs/hour (depending on the wire)
Casing Compatibility Range:1.0φ/6.5φ standard (7.0 or more customized)
Casing baking length:4mm-50mm (optional jig)
Baking temperature:200°C-380°C (adjustable by thermostat)
Pneumatic:5.5/6.5KPa
Temperature:0℃-50℃
Humidity level:10%RH~90%RH (no condensation)
Anti-interference capability:Interference voltage: 1500Vp-p Pulse period: 1us Duration: 1 minute
TR-H14 Semi-automatic Heat Shrink Tube Baking Machine
TR-H14 Semi-automatic Heat Shrink Tube Baking Machine
Casingbaking length:4MM-50MM(optional)
Baking temperature:200°C-380°C(adjustable by thermostat)
Pneumatic:5.5/6.5KPa
Temperature:0℃-50℃
Weights:Approx.78KG
Humidity level:10%RH~90%RH(no condensation)
Anti-interference capability:Interference voltage: 1500Vp-p Pulse period: 1us Duration: 1 minute
TR-H14 Semi-automatic Heat Shrink Tube Baking Machine
utomatic wire Wear tube heat shrink machine, insert tube heat insulator wire threading, View wire connection machine
This machine only wears the tube without forming, the customer provides wire samples, and the customized machine according to the samples provided.
Manual pay off, automatic pipe cutting, automatic pipe threading, automatic banking, one-time completion.
Fast positioning speed and precision through the pipe.
The large screen and buttons are clear at a glance, making the operation more convenient.
After the set baking time, the heating tube will automatically return to its original position, and the finished wire can be taken out by opening the guide clip.
