TR-GD05 high-end full Mitsubishi servo OTP mold double-head terminal crimping machine

TR-GD05 high-end full Mitsubishi servo OTP mold double-head terminal crimping machine

TR-GD05 high-end full Mitsubishi servo OTP mold double-head terminal crimping machine
TR-GD05 high-end full Mitsubishi servo OTP mold double-head terminal crimping machineTR-GD05 high-end full Mitsubishi servo OTP mold double-head terminal crimping machineTR-GD05 high-end full Mitsubishi servo OTP mold double-head terminal crimping machineTR-GD05 high-end full Mitsubishi servo OTP mold double-head terminal crimping machineTR-GD05 high-end full Mitsubishi servo OTP mold double-head terminal crimping machine
CategoriesFully Automatic Terminal Crimping Machine
BrandTuring
ModelTR-GD05
PowerAC220V/50HZ,
Applicationterminal crimping machine
FeatureStable Performance
Warranty1year
ContactCoco:+8618666170785
FOB portshenzhen ,guangzhou ,zhongshan
Terms of PaymentWestern Union, MoneyGram, T/T
Download
Update TimeDec 3,2024
Detail Information
TR-GD05 high-end full Mitsubishi servo OTP mold double-head terminal crimping machine
Appearance dimensions: length 1380*width 750*1580 height (mm)
Machine weight 360Kg
Working voltage AC220V 50Hz
Working air pressure 0.5~0.6MPa (stable, clean, dry)
Rated power 1.8KW
Machine functions: wire cutting, double-end stripping, single-end half-stripping, single-end single-end crimping, single-wire double-end crimping.
Cutting wire length 26mm~9999mm
Cutting tolerance ≥1m, ±0.02% or less
Peeling length 0.5mm~35mm (over 12mm, half peeling is required)
Cutting speed 5500 lines/h (within 100mm)
Processing efficiency 4000~4800/h (within 30~200mm)
End pressure: standard 2.0T, other pressures can be customized
Applicable wire AWG30#~14#
Applicable molds: OTP transverse mold, straight mold (European mold can be customized)
Motor: 5 sets of Japanese Mitsubishi servo motors + 2 sets of stepper motors
Screw: 4 sets of TBI screws
Slide rail 7 sets of silver guide rails
Bearings Sweden SKF
Terminal crimping capacity 2T/3T European precision frequency conversion terminal machine
TR-GD05 high-end full Mitsubishi servo OTP mold double-head terminal crimping machine
